MAX478

17µA Max, Dual Quad, Single-Supply, Precision Op Amps

Data Sheet (Rev. 1)

Viewing:

Part Details

17µA Max Supply Current (MAX478A/MAX479A)
70µV Max Offset Voltage (MAX478A)
Single-Supply Operation:
- Input Voltage Range Includes Ground
- Output Swings to Ground While Sinking Current
- No Pull-Down Resistors Required
Dual Op Amp in 8-Pin DIP/SO Package (MAX478)
Quad Op Amp in 14-Pin DIP/SO Package (MAX479)
250pA Max Input Offset Current (MAX478A/MAX479A)
0.5µV/°C Offset-Voltage Drift
Output Sources and Sinks 5mA Load Current

Documentation

Data Sheet 1

MAX478-MAX479: 17µA Max, Dual Quad, Single-Supply, Precision Op Amps Data Sheet (Rev.1) 11/01/1998

Design Note 1

PC Printer Port Controls I-V Curve Tracer 07/01/2001

Technical Articles 1

Making Low Power and Low Voltages Work in Analog Design 01/22/2002

This is the most up-to-date revision of the Data Sheet.
