MAX44280

PRODUCTION

1.8V, 50MHz, Low-Offset, Low-Power, Rail-to-Rail I/O Op Amp

High Bandwidth and Excellent V_OS Accuracy Over Time and Temperature

Data Sheet (Rev. 2)

Part Models: 4
1ku List Price: Starting From $1.10

Viewing:

Part Details

Low 1.8V Supply Rail Over the -40°C to +125°C Range
1.7V Supply Rail Over the 0°C to +70°C Range
50MHz Bandwidth
Low 12.7nV/ Input Voltage-Noise Density
Low 1.2fA/ Input Current-Noise Density
Low 50µV (max) V_OS at +25°C
500fA Low Input Bias Current
750µA Quiescent Current per Amplifier
< 1µA Supply Current in Shutdown
Small, 2mm x 2mm SC70 and 1mm x 1.5mm Thin µDFN Packages
Low -110dB Total Harmonic Distortion
5V/V Minimum Stable Gain

Part Models: 4
1ku List Price: Starting From $1.10

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX44280AXT+	Single Chip Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44280AXT+T	Single Chip Package	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44280AYT+	6-LGA-1.5X1X0.5	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX44280AYT+T	6-LGA-1.5X1X0.5	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
