MAX40658

PRODUCTION

Transimpedance Amplifier with 100mA Input Current Clamp for LiDAR Applications

TIA Ideal for Industrial and Automotive LIDAR Applications

Data Sheet (Rev. 4)

Part Models: 2
1ku List Price: Starting From $3.16

Viewing:

Part Details

45nA_RMS Noise
Two Transimpedance Values Available
- 18kΩ (MAX40658)
- 36kΩ (MAX40659)
360MHz Minimum Bandwidth
Internal Clamp For Input Current Up To 100mA
Offset Adjust Input
70mW Power Dissipation
3.3V Operation

Part Models: 2
1ku List Price: Starting From $3.16

Documentation

Data Sheet 1

MAX40658-MAX40659: Transimpedance Amplifier with 100mA Input Current Clamp for LiDAR Applications Data Sheet (Rev.4) 04/11/2022

Evaluation Design File 1

MAX40658 Gerber File 10/10/2022

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX40658ETA+	8-LFCSP-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX40658ETA+T	8-LFCSP-3X3X0.75	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

SPICE Model 1

MAX40658 Spice Model SPICE Macro Model
