MAX3509

Upstream CATV Amplifier

Cable Upstream Amplifier Provides 66dBmV Output Level from 5MHz to 65MHz

Data Sheet (Rev. 1)

Viewing:

Part Details

Ultra-Low Power-Up/Down Transients, 25mV (typ) at 66dBmV Output
Single-Supply Operation
Output Level Ranges from <12dBmV to 67dBmV (QPSK)
Gain Programmable in 1dB Steps
Low Transmit Output Noise Floor: -41dBmV (160kHz BW)
Low Transmit-Disable Output Noise: -70dBmV
Shutdown Mode

Documentation

Data Sheet 1

MAX3509: Upstream CATV Amplifier Data Sheet (Rev.1) 07/29/2005

Technical Articles 2

Converting S-Parameters from 50Ω to 75Ω Impedance 11/21/2003

PCBs Layout Guidelines for RF & Mixed-Signal 09/14/2011

This is the most up-to-date revision of the Data Sheet.
