LTC6103

RECOMMENDED FOR NEW DESIGNS

Dual High Voltage, High Side Current Sense Amplifier

Data Sheet Product Selection Table

Part Models: 6
1ku List Price: Starting From $2.02

Viewing:

Part Details

Two Independent Current Sense Amplifiers
Wide Supply Range: 4V to 60V, 70V Absolute Maximum
Low Offset Voltage: 450µV Maximum
Fast Response: 1µs Response Time
Gain Configurable with External Resistors
Low Input Bias Current: 170nA Maximum
PSRR: 110dB Minimum (6V to 60V)
Output Current: 1mA Maximum
Low Supply Current: 275µA per Amplifier, V_S = 12V
Specified for –40°C to 125°C Temperature Range
Available in an 8-lead MSOP Package

Part Models: 6
1ku List Price: Starting From $2.02
