HMC414

RECOMMENDED FOR NEW DESIGNS

InGaP HBT Power Amplifier SMT, 2.2 - 2.8 GHz

Data Sheet Product Selection Table

Part Models: 2
1ku List Price: price unavailable

Viewing:

Part Details

Gain: 20 dB
Saturated Power: +30 dBm
32% PAE
Supply Voltage: +2.75V to +5V
Power Down Capability
Low External Part Count

Part Models: 2
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC414 Data Sheet 04/22/2015

Application Note 4

Thermal Management for Surface Mount Components General Application Note 11/11/2015

AN-1363: Meeting Biasing Requirements of Externally Biased RF/Microwave Amplifiers with Active Bias Controllers 05/13/2020

AN-1604: Thermal Management Calculations for RF Amplifiers in LFCSP and Flange Packages 08/01/2019

AN-2591: When It Comes to Long-Term Reliability of RF Amplifier ICs, Focus First on Die Junction Temperature 08/05/2024

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC414MS8GE	8-Lead MSOP w/ EP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC414MS8GETR	8-Lead MSOP w/ EP	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

May 6, 2019 - 19_0063 Assembly Site Transfer of Select MSOP and SOIC_N E-pad Devices to Carsem Malaysia
		PCN19_0063_Form Material_Report Other Qualification Results Summary Qualification Results Summary Other
HMC414MS8GE	PRODUCTION
HMC414MS8GETR	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
