HMC375

LAST TIME BUY

GaAs pHEMT MMIC Low Noise Amplifier, 1.7 - 2.2 GHz

Data Sheet Product Selection Table

Part Models: 2
1ku List Price: price unavailable

Viewing:

Part Details

Noise Figure: 0.9 dB
Output IP3: +34 dBm
Gain: 17 dB
Very Stable Gain vs. Supply & Temperature
Single Supply: +5V @ 136 mA
50 Ohm Matched Output

Part Models: 2
1ku List Price: price unavailable

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC375LP3E	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC375LP3ETR	16-Lead QFN (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jun 6, 2022 - 22_0048 Addition of ASE Korea as an Alternate Assembly Site for Select LFCSP Products
		PCN22_0048_Form Material_Report Qualification Results Summary Detailed Change Description
HMC375LP3E	LAST TIME BUY
HMC375LP3ETR	LAST TIME BUY
Aug 28, 2019 - 19_0204 Moisture Sensitivity Level Rating Change for Select Packaged Products
		PCN19_0204_Form Material_Report Qualification Results Summary Qualification Results Summary
HMC375LP3E	LAST TIME BUY
HMC375LP3ETR	LAST TIME BUY
Sep 3, 2020 - 20_0057 Discontinuance of Model Numbers: HMC549MS8GE, HMC375LP3E, HMC382LP3E, HMC-AUH318, HMC-ALH508, HMC-AUH317G, HMC-ALH509G, HMC-ALH311, HMC-APH460, HMC-AUH232, HMC-APH196
		PDN20_0057_Form Material_Report
HMC375LP3E	LAST TIME BUY
HMC375LP3ETR	LAST TIME BUY

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

ADIsimRF

ADIsimRF is an easy-to-use RF signal chain calculator. Cascaded gain, noise, distortion and power consumption can be calculated, plotted and exported for signal chains with up to 50 stages. ADIsimRF also includes an extensive data base of device models for ADI’s RF and mixed signal components.

Open Tool

S-Parameter 1

HMC375 S-Parameters

Sys-Parameter Models for Keysight Genesys

Sys-Parameter models contain behavioral parameters, such as P1dB, IP3, gain, noise figure and return loss, which describe nonlinear and linear characteristics of a device.

Open Tool
