ADH659S

Aerospace, GaAs, PHEMT, MMIC, Power Amplifier, DC to 15 GHz

Viewing:

Part Details

  • P1dB Output Power: +26.5 dBm
  • Gain: 19 dB
  • OIP3: +35 dBm
  • Single Supply: +8V @ 300 mA
  • 50 Ohm Matched Input/Output
  • Die Size: 3.06 mm x 1.559 mm x 0.1 mm
  • Screened in accordance with MIL-PRF-38534, Class K
ADH659S
Aerospace, GaAs, PHEMT, MMIC, Power Amplifier, DC to 15 GHz
HMC8418 SID
