ADH635S

Aerospace, GaAs, PHEMT, MMIC, Driver Amplifier, 18 GHz to 40 GHz

Viewing:

Part Details

  • Gain: 19.5 dB
  • P1dB: +23 dBm
  • Output IP3: 29 dBm
  • Saturated Power: + 24 dBm @ 15% PAE
  • Single Voltage: +5V @ 280 mA
  • 50 Ohm Matched Input/Output
  • Small Die Size: 1.95 mm x 0.84 mm x 0.1 mm
  • Screened in accordance with MIL-PRF-38534, Class K
ADH635S
Aerospace, GaAs, PHEMT, MMIC, Driver Amplifier, 18 GHz to 40 GHz
HMC6987 SID
