ADH499S

RECOMMENDED FOR NEW DESIGNS

Aerospace GaAs PHEMT, Medium Power Amplifier 21 to 32 GHz, LSH6 Package

Data Sheet (Rev. A) Product Selection Table

Part Models: 1
1ku List Price: price unavailable

Viewing:

Part Details

Gain: 17dB
Noise Figure: 5.0dB
OIP3: +34dBm
P1dB: +23dBm

DC Block RF I/Os
Gate Control
50 Ohm Matched Input/Output

Part Models: 1
1ku List Price: price unavailable

Documentation

Data Sheet 1

ADH499S: Medium Power Amplifier 21 – 32 GHz Data Sheet (Rev.A) 10/11/2023

Application Note 1

AN-2591: When It Comes to Long-Term Reliability of RF Amplifier ICs, Focus First on Die Junction Temperature 08/05/2024

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
ADH499-701LSH6	CER LDLESS CHIP W/HEATSINK	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.
