AD841

PRODUCTION

Wideband, Unity-Gain Stable, Fast Settling Op Amp

Data Sheet (Rev. C) Product Selection Table

Part Models: 5
1ku List Price: Starting From $7.97

Viewing:

Part Details

Unity-Gain Bandwidth: 40 MHz
Fast Settling: 110 ns to 0.01%
Slew Rate: 300 V/µs
Full Power Bandwidth:
4.7 MHz for 20 V p-p into a 500 Ω load
Input Offset Voltage: 1mV max
Input Voltage Noise:
15 nV/√Hz typ
Open-loop gain:
45 V/mV into a 1 kΩ load
Output current: 50 mA min
Supply current: 12 mA max

Part Models: 5
1ku List Price: Starting From $7.97

Documentation

Data Sheet 2

AD841: Wideband, Unity-Gain Stable, Fast Settling Op Amp Data Sheet (Rev.C) 09/18/2008

AD841: Military Data Sheet 10/14/2002

Application Note 2

AN-581: Biasing and Decoupling Op Amps in Single Supply Applications (Rev.0) 02/14/2015

AN-402: Replacing Output Clamping Op Amps with Input Clamping Amps 08/07/2023

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
5962-89641012A	20 ld LCC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD841JNZ	14-Lead PDIP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD841SE/883B	20-Lead LCC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD841SQ	14-Lead CerDIP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD841SQ/883B	14-Lead CerDIP	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Apr 9, 2018 - 16_0026 Qualify TeamQuest Technology, Inc. for Burn-in and Life Test of Military and Aerospace Devices
		PCN16_0026_Form Material_Report Qualification Results Summary
5962-89641012A
AD841SE/883B
AD841SQ/883B
Jun 6, 2012 - 12_0066 Add capacity for Burn In of Hermetic, 883 & QMLQ/Class B devices at TSSI Cavite
		PCN12_0066_Form Material_Report Qualification Report Summary
5962-89641012A
AD841SE/883B
AD841SQ/883B
Nov 9, 2011 - 11_0050 Transfer of ADI Hermetics Assembly location from Paranaque, Manila to General Trias, Cavite Philippines
		PCN11_0050_Form Material_Report
5962-89641012A
AD841SE/883B
AD841SQ
AD841SQ/883B
Nov 9, 2011 - 11_0182 Test Site Transfer from Analog Devices Philippines Inc in Paranaque to Analog Devices General Trias in Cavite, Philippines
		PCN11_0182_Form Material_Report
5962-89641012A
AD841SE/883B
AD841SQ
AD841SQ/883B
Mar 29, 2021 - 21_0033 Assembly Site Transfer for 14/16L 300_MIL PDIP to Cirtek
		PCN21_0033_Form Material_Report Detailed Change Description Qualification Results Summary
AD841JNZ	PRODUCTION
Aug 19, 2009 - 07_0024 Package Material Changes for SOT23, MiniSO, MQFP, PDIP, PLCC, SOIC (narrow and wide body), SSOP, TSSOP and TSSOP exposed pad
		Material_Report Material_Report Parts List PCN07_0024_Form Qual Data
AD841JNZ	PRODUCTION
Nov 7, 2012 - 12_0199 Qualification of New Conductive Silver-Filled Glass Die Attach Adhesive for Cerdip and Ceramic Flatpack (Cerpack) Packages.
		PCN12_0199_Form Material_Report Qualification Report Summary Datasheet Specification Comparison
AD841SQ
AD841SQ/883B

This is the most up-to-date revision of the Data Sheet.
