AD8208

PRODUCTION

High Voltage, Precision Difference Amplifier

Data Sheet (Rev. C)

Part Models: 10
1ku List Price: Starting From $1.97

Viewing:

Part Details

AEC-Q100 qualified
EMI filters included
High common-mode voltage range
−2 V to +45 V operating
−24 V to +80 V survival
Buffered output voltage
Gain = 20 V/V
Low-pass filter (single-pole or two-pole)
Wide operating temperature range
8-lead SOP & MSOP: −40°C to +125°C
Excellent ac and dc performance
±1 mV voltage offset
−5 ppm/°C typical gain drift
80 dB CMRR minimum dc to 10 kHz

Part Models: 10
1ku List Price: Starting From $1.97

Documentation

Data Sheet 1

AD8208: High Voltage, Precision Difference Amplifier Data Sheet (Rev.C) 01/30/2010

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
AD8208WBRMZ	8-Lead MSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WBRMZ-R7	8-Lead MSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WBRMZ-RL	8-Lead MSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WBRZ	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WBRZ-R7	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WBRZ-RL	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WHRMZ	8-Lead MSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WHRMZ-RL	8-Lead MSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WHRZ	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys
AD8208WHRZ-RL	8-Lead SOIC	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Oct 26, 2015 - 15_0176 Assembly Transfer of Select 8/10L MSOP Products to Amkor Philippines
		PCN15_0176_Form Material_Report Detailed Change Description Qualification Results Summary Qualification Results Summary
AD8208WBRMZ	PRODUCTION
AD8208WBRMZ-R7	PRODUCTION
AD8208WBRMZ-RL	PRODUCTION
AD8208WHRMZ	PRODUCTION
AD8208WHRMZ-RL	PRODUCTION
Jan 20, 2014 - 14_0006 AD8208 ESD Improvement
		PCN14_0006_Form Material_Report Qualification Report Summary
AD8208WBRMZ	PRODUCTION
AD8208WBRMZ-R7	PRODUCTION
AD8208WBRMZ-RL	PRODUCTION
AD8208WBRZ	PRODUCTION
AD8208WBRZ-R7	PRODUCTION
AD8208WBRZ-RL	PRODUCTION
AD8208WHRMZ	PRODUCTION
AD8208WHRMZ-RL	PRODUCTION
AD8208WHRZ	PRODUCTION
AD8208WHRZ-RL	PRODUCTION
Jul 20, 2012 - 12_0105 Halogen Free Material Change for Select SOIC Narrow and Wide Body Products Assembled at Amkor
		PCN12_0105_Form Material_Report Qualification Report Summary
AD8208WBRZ	PRODUCTION
AD8208WBRZ-R7	PRODUCTION
AD8208WBRZ-RL	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

SPICE Model 1

AD8208 SPICE Macro Model
