AD6630

Obsolete

Differential, Low Noise IF Gain Block with Output Clamping

Data Sheet (Rev. 0) Product Selection Table

Part Models: 1
1ku List Price: price unavailable

Viewing:

Part Details

24 dB Gain
4 dB Noise Figure
Easy Match to SAW Filters
Output Limiter Adjustable +8.5 dBm to +12 dBm

700 MHz Bandwidth
10 V Single or Dual 5 V Power Supply
300 mW Power Dissipation

Part Models: 1
1ku List Price: price unavailable

Documentation

Application Note 2

AN-669: Effectively Applying the AD628 Precision Gain Block (Rev.0) 02/14/2015

AN-835: Understanding High Speed ADC Testing and Evaluation 07/01/2020

Obsolete Data Sheet 1

AD6630: Differential, Low Noise IF Gain Block with Output Clamping Data Sheet (Rev.0) 10/30/1998

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
AD6630AR	16-Lead SOIC Wide	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Aug 4, 2010 - 10_0117 Halogen Free Material Change for SOIC_W Products at Carsem
		PCN10_0117_Form Material_Report Reliability Report
AD6630AR	Obsolete	PCN10_0117_Form Material_Report Reliability Report
Sep 10, 2012 - 11_0112 ADI Corporate Obsolescence Notice-October 2011 (Standard Products)
		PDN11_0112_Form Material_Report
AD6630AR	Obsolete	PDN11_0112_Form Material_Report

This is the most up-to-date revision of the Data Sheet.
