MAX33046E

• Metrology subsystem plus selected other features of a level 2, 7kW to 22kW electric vehicle supply equipment (EVSE)
• Full-featured board for ADE9112, ADE9113, and ADE9178
• Rated up to three phase, 240V RMS line to neutral voltage
• Rated up to 32A current measurement with on-board shunts
• Supports up to 22kW combined power transfer to load
• Features MAX32672 low power, secure microcontroller
• Supports LCD display for energy and state updates
• Supports MODBUS™ protocol over RS-485 communication interface
• Supports Protobuf™ messages to communicate with EVerest open source software (OSS)
• IEC61851-compatible state machine implementation

The AD-ACEVSE22KWZ-KIT is a reference design for the metrology subsystem plus selected other features of a level 2, 7 kW to 22 kW AC electric vehicle supply equipment (EVSE). It includes the ADE9113 isolated Σ-Δ analog-to-digital converter (ADC) coupled with the ADE9178 metrology DSP to accurately measure energy delivered to an electric vehicle (EV). It includes the MAX32672 ultralow- power ARM^® Cortex^®-M4 processor, a cost-effective, highly integrated, and highly reliable 32-bit microcontroller to accumulate energy measurements and securely send it to a host for display. A charge control state machine is run on the microcontroller to transition through different charge states when a charging plug is inserted into an electric vehicle. The kit includes a flexible printed circuit (FPC) connector and LCD to read the energy measurements and state transitions during a charging cycle. The power input/output, control pilot (CP), and proximity pilot (PP) signals are exposed on connectors at the edge of the board. The energy delivered to the EV is measured as a voltage drop across shunts and a resistor ladder network, which makes it easy to set up the boards in the field.

• 轻松评估MAX33046E/MAX33045E
• I/O接口兼容性（1.71V至5.5V）
• 经过验证的PCB布局
• 兼容Arduino^®/Arm^® Mbed^™平台
• 装配完成且经过测试

MAX33046E屏蔽体是一款装配完善且经过测试的印刷电路板(PCB)，可演示MAX33046E半双工RS-485收发器的功能，具有±25V故障保护、扩展-7V至+12V共模范围以及用于A/B数据线路的±40kV ESD人体模型(HBM)。该屏蔽体具有数字隔离器，用作RS-485收发器和控制器接口之间的电平转换器。

应用

• 背板总线
• 编码器接口
• 工厂自动化设备
• 运动控制器
• 可编程控制器
• 电信设备
