MAX86916
RECOMMENDED FOR NEW DESIGNSIntegrated Optical Sensor Module for Mobile Health
Multi Wavelength Integrated Optical Sensor Module for Wearables
- Part Models
- 2
- 1ku List Price
- Starting From $7.56
Part Details
- Miniature 3.5mm x 7.0mm x 1.5mm, 14-Pin Optical Module
- Optical-Grade Glass for Long-Term Optimal and Robust Performance
- Ultra-Low-Power Operation for Mobile Device
- Ultra-Low Shutdown Current (0.7µA, Typical)
- Built-In Low Noise Crosstalk Cancellation
- -40°C to +85°C Operating Temperature Range
- Reflective Heart Rate Monitor, Medical-Grade Pulse Oximeter, and Bio-Optical Sensor Platform
The MAX86916 is an integrated optical sensor platform with applications in bio-sensing, proximity, and color. It includes internal LEDs, photodetectors, and low-noise electronics with ambient-light-rejection circuitry. The MAX86916 helps ease design-in effort to all mobile and wearable devices.
The MAX86916 operates on a 1.8V supply voltage, with a separate 5.5V power supply for the internal LEDs. Communication to and from the module is accomplished entirely through a standard I2C-compatible interface. The module can be shut down through software with nearzero standby current, allowing the power rails to remain powered at all times.
Applications
- Smartphones/Accessories
- Tablets
- Wearable Devices
- Fitness Assistant Devices
Documentation
Video 1
3rd Party Solutions 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| MAX86916EFD+ | 14-LGA_CAV-7X3.5X1.5 | ||
| MAX86916EFD+T | 14-LGA_CAV-7X3.5X1.5 |
This is the most up-to-date revision of the Data Sheet.
